Piston Assembly Φ84.5mm Fit For Audi A4 A5 Q5 Q7 VW Touareg 3.0T V6 06E107065DM

Piston assemblies for the Audi C6 3.0T V6 (Standard/STD specification) typically feature an 84.51 mm bore diameter, a 22 mm piston pin diameter, and a three-ring configuration (with 1.2 mm for both the first and second rings, and a 2.0 mm oil ring). These aluminum alloy pistons are specifically engineered for 2995cc displacement engines and are commonly compatible with CREC/CRED engine codes; notably, the 84.51 mm dimension represents the standard diameter for this series (i.e., not an oversized dimension).

Category: Tag:

Description

Key Piston Specifications (3.0T):
Cylinder Bore: Standard (STD) — 84.51 mm.
Piston Pin Diameter: 22.00 mm.
Piston Ring Details:
Top Ring: 1.2 mm.
Second Ring: 1.2 mm.
Oil Ring: 2.0 mm.
Engine Type: V6 3.0 TFSI (Supercharged), 24-Valve DOHC.
Material: ZL109 Aluminum Alloy.
Replacement Part Note: Compatible with OE Part Numbers including 06E 107 065 EC/DS.
