G6EA Intake & Exhaust Valves — Compatible with Hyundai Santa Fe / Kia Optima — 22211-3E000 / 22212-3E000
The Hyundai G6EA 2.7L V6 engine features a 24-valve design with a valve seat angle of 45° and a valve stem diameter of approximately 6 mm. The intake valve clearance is 0.17–0.23 mm, while the exhaust valve clearance is 0.27–0.33 mm. The valve lengths are 110.1 mm (intake) and 111.1 mm (exhaust), and the valve clearances are 1.0 mm (intake) and 1.3 mm (exhaust), respectively.
Description
Hyundai G6EA (2.7L V6) Key Valve Specifications
Valve Clearance (Cold):
Intake: 0.17–0.23 mm (0.0067–0.0090 in.)
Exhaust: 0.27–0.33 mm (0.0106–0.0129 in.)
Valve Length:
Intake: 110.1 mm (4.3346 in.)
Exhaust: 111.1 mm (4.3740 in.)
Valve Stem Diameter:
Intake: 5.965–5.980 mm (0.2348–0.2354 in.)
Exhaust: 5.950–5.965 mm (0.2343–0.2348 in.)
Valve Margin Thickness (Minimum):
Intake Valve: 1.0 mm (0.0394 in.)
Exhaust Valve: 1.3 mm (0.0512 in.)
Valve Seat Angle: 45°–45.5°
Valve Spring Free Length: 46.8 mm (1.8425 in.)
Diameter: 29.964–29.980 mm (1.1797–1.1803 in.)
OE Numbers: 22211-3E000, 22212-3E000
