For Wuling Yangguang N1 1.3L LJ474QE2 5MT gasoline engine 2003-2006

The Wuling 474Q engine, often identified as part of the LJ474Q or JL474Q series, is a1.3-liter (1300cc) inline four-cylinder gasoline engine commonly used in Wulingminivans, microvans, and light commercial vehicles

Category: Tag:

Description

Key Technical Specifications (Approximate Values):
Engine Type: 4-stroke, Inline-4, Water-cooled
Displacement: 1.3L (approx. 1300cc)
Max. Power: 60 kW – 67 kW (approx. 80–90 hp)  6000 rpm
Max. Torque: ~102 N·m – 112 N·m (approx. 75–83 lb-ft)
Fuel Type: Gasoline
Emission Standard: Typically Euro II to Euro IV standards
Material: Aluminum alloy cylinder head, typically paired with a cast iron or aluminum alloy cylinder block
Configuration: DOHC (Double Overhead Camshaft) or SOHC; 4 valves per cylinder
Firing Order: 1-3-4-2
Bore x Stroke: ~75.0 mm x 84.0 mm

Common Applications:
W-Collar Series (Yangguang, Hongtu, Zhiguang, Xiaojun), Changan, Xingchen, Suzuki
