For the Toyota Mark X (Chinese Market) and Toyota Crown models (5GR)

The Toyota 5GR-FE is a 2.5-liter (2,497 cm³) V6 engine belonging to the GR series. It is primarily featured in Toyota models targeted at the Chinese market, such as the Crown and Reiz. This engine typically produces approximately 193–197 PS (142–145 kW) of power at 6,200 rpm, with a peak torque of 242 N·m (178 lb-ft). Its design characteristics include a 60-degree V-angle, an aluminum cylinder block, and a DOHC valve train equipped with Dual VVT technology.

Category: Tag:

Description

Toyota 5GR-FE Engine Key Specifications:
Engine Type: 6-cylinder, V-type (V6), four-stroke gasoline engine
Displacement: 2.5 liters (2497 cm³)
Bore × Stroke: 87.5 mm × 69.2 mm
Max Power: Approx. 145 kW (197 PS or 194 hp) at 6200 rpm; Max Torque: 242 N·m (178 lb-ft) at 4400 rpm
Valve Mechanism: DOHC (Dual Overhead Camshaft), 4 valves per cylinder (24 valves total)
Fuel System: EFI (Electronic Fuel Injection), Dual VVT-i (Intelligent Variable Valve Timing)
Cylinder Block Material: Cast aluminum alloy
Cylinder Liners: Spiny-type cast iron liners
Compression Ratio: Designed for high efficiency; commonly used in sedan models paired with automatic transmissions

Application: Primarily found in Toyota Mark X (Chinese market) and Toyota Crown models.
