Subaru EZ36 3.6L Engine
Subaru EZ36 3.6L Engine
  1. Subaru EZ36 3.6L Engine
  2. Subaru EZ36 3.6L Engine

For Subaru WX 3.6R 3.6L EZ36 5A/MT gasoline engine

The Subaru EZ36 is a 3.6-liter horizontally opposed six-cylinder (Boxer) engine produced from 2008 to 2019, renowned for its smooth power delivery and reliability. With a displacement of 3,629 cc, the engine produces 256 horsepower (191 kW) at 6,000 rpm and 247 lb-ft (334 Nm) of torque at 4,400 rpm. It features a Dual Overhead Camshaft (DOHC) layout, equipped with 24 valves and Dual AVCS (Active Valve Control System).

Category: Tag:

Description

Key Technical Specifications
Engine Code: EZ36D
Configuration: Horizontally Opposed 6-Cylinder (Boxer)
Displacement: 3.6L (3,629 cc)
Bore & Stroke: 92 mm (Bore) × 91 mm (Stroke)
Compression Ratio: 10.4:1
Valve Train: DOHC (Dual Overhead Camshafts), 4 valves per cylinder (24 valves total), Dual AVCS
Fuel System: Multi-Point Fuel Injection (MPI)
Max Horsepower: Approx. 256 hp (191 kW) @ 6,000 rpm
Max Torque: Approx. 247 lb-ft (334 Nm) @ 4,400 rpm
Redline: Approx. 6,500 rpm
Fuel Type: Premium Unleaded Gasoline (Recommended)

Applicable Models: 2010–2019 Subaru Outback, 2010–2019 Subaru Legacy, 2008–2014 Subaru Tribeca
