For Audi A4, A6 (C6) Quattro 2002–2006

Engine for Audi A4 / A6 (C6) Quattro 2002–2006 3.0L (BBJ)

The Audi BBJ is a 3.0-liter naturally aspirated V6 gasoline engine, primarily utilized in Audi models such as the A4, A6, and A8 during the early to mid-21st century. This engine features a 30-valve design (five valves per cylinder), multi-point fuel injection technology, and an aluminum cylinder block.

Description

The Audi BBJ engine is a 3.0-liter, naturally aspirated, 30-valve V6 gasoline engineproduced from 2000 to 2008. It was commonly utilized in the Audi A4 (B6/B7) and AudiA6 (C5)

Key Technical Specifications:
Engine Configuration: 90° V6, DOHC
Valve Mechanism: 30 valves (5 valves per cylinder), Variable Valve Timing
Displacement: 2976 cm³ (181.6 cu in)
Bore x Stroke: 82.5 mm x 84.2 mm (3.25 in x 3.31 in)
Compression Ratio: 10.5:1 (may vary slightly depending on market/emission regulations)
Power Output: 160 kW (217 hp / 220 PS) 6300 rpm
Torque Output: 300 Nm (221 lb-ft) 3200 rpm
