For Benz E260 1.8T L4 engine

E260 Engine for Mercedes-Benz 1.8T

The 1.8T L4 engine featured in the Mercedes-Benz E260 (typically referring to the 2010–2013 model years, chassis codes W212/C207) is an M271.860 CGI turbocharged gasoline engine with direct injection and a displacement of 1.8 liters (1796 cc). This engine typically produces a maximum power output of 150 kW (approximately 201–204 horsepower) and a peak torque of 310 Nm, and is commonly paired with a 5-speed or 7-speed automatic transmission.

Description

Key Engine Specifications:
Engine Code: M271.860 (depending on the specific model variant; may also be M271.820/861)
Engine Type: 1.8L Inline-4 CGI (Gasoline Direct Injection) Turbocharged
Displacement: 1796 cc
Max Power: 150 kW (204 PS / 201 hp)
Peak Torque: 310 Nm (228 lb-ft)
Bore: Ø82.00 mm
Fuel Type: Gasoline

Performance Specifications:
Turbocharger: Twin-scroll turbocharger (IHI RHF4)
Injection System: CGI (Charged Gasoline Injection) Direct Injection
Cylinder Configuration: Inline-4 (L4)
Acceleration (E260L): 0–100 km/h in just 8.6 seconds
Top Speed (E260L): 238 km/h
