Crankshaft for 2008–2024 Lexus, Toyota, and Scion 1.8L 2ZR Engines

The crankshaft for the Toyota 2ZR series (such as the 2ZR-FE, 2ZR-FXE, etc.) is a lightweight cast-iron component designed for 1.8-liter inline-four engines. It utilizes a cylinder offset (*desaxage*) layout aimed at reducing friction and internal wear.

Category: Tag:

Description

Core Dimensions
Stroke: 88.30 mm
Main journal diameter: 47.99 mm (standard)
Connecting rod journal diameter: 43.99 mm (standard)
Rear oil seal diameter: 78.00 mm

Maintenance and Clearance Data
Main bearing oil film clearance: 0.024 – 0.049 mm (depending on bearing grade)
Connecting rod bearing oil film clearance: 0.025 – 0.045 mm
Thrust bearing axial clearance: 0.020 – 0.220 mm

Applicable models: Commonly found in the Toyota Corolla, Prius, and Matrix, as well as the Scion xD.
