Crankshaft 8-94139669-0 8941396690 8941597680 for Isuzu C240 C240PKJ Engine

The Isuzu C240 ​​diesel engine crankshaft (commonly used in forklifts) has a stroke of 102.00 mm, a main journal diameter of 69.92–70.00 mm, and a crankpin (connecting rod) journal diameter of 52.92–53.00 mm. It is a 4-cylinder, 5-main-bearing unit with a total length of approximately 563–564 mm and a rear oil seal diameter of 82.00 mm.

Category: Tag:

Description

Key Technical Parameters:

Stroke: 102.00 mm

Main Journal Diameter: 69.92 mm – 70.00 mm

Crankpin Journal Diameter: 52.92 mm – 53.00 mm

Rear Oil Seal Diameter: 82.00 mm

Overall Length: Approx. 563–564 mm

Main Bearings: 5

Flywheel Bore Holes: 6

Connecting Rod Bolt Torque: 57-65 Nm

Crankshaft Pulley Bolt Torque: 122-151 Nm

OEM Compatible Codes: 8-941396-690, 8-941597-680, 9-12310-413-0
