Crankshaft 13401-31011 for Toyota Tacoma, Tundra, 4Runner, and FJ Cruiser 4.0 V6 1GR-FE engines.

Description

Specifications:
Stroke: 95.0 mm (3.74 in)
Main journal diameter: 71.988 – 72.000 mm (2.8342 – 2.8346 in)
Connecting rod journal (crankpin) diameter: 55.992 – 56.000 mm (2.2044 – 2.2047 in)
Total length: Approx. 479.5 – 481.0 mm
Thrust clearance: Standard value 0.04 – 0.24 mm (0.0016 – 0.0094 in);
Maximum limit 0.30 mm

Main bearing cap bolts:
Step 1: 61 Nm (45 ft-lb)
Connecting rod bolts:
Step 1: 25 Nm (18 ft-lb)
Step 2: Rotate the bolts an additional 90 degrees
