For Volkswagen EA111 1.4L Engine (CFB)

CFB for Volkswagen EA111 1.4L Engine

The Volkswagen EA111 1.4T CFB (typically designated as CFBA) is a 1.4-liter turbocharged, direct-injection gasoline engine within the EA111 series, producing an output of approximately 96 kW (131 hp) and a torque of around 220 Nm (160 lb-ft). This 1,390 cc inline-four engine is commonly found in models such as the Volkswagen Golf Mk6, Jetta V, and Škoda Octavia, and is notable for its use of a single turbocharger.

Description

Key Technical Specifications (CFB / CFBA):
Engine Series: EA111
Displacement: 1390 cc (1.4L)
Cylinder Configuration: Inline-4
Induction Type: Single Turbocharger (No Supercharger)
Max Power: Approx. 96 kW (131 PS / 134 hp)
Max Torque: Approx. 220 Nm (160 lb-ft / 162 lb-ft) 1,750–3,500 rpm
Fuel System: Direct Injection (TSI)
Fuel Type: Gasoline
Valve Train: DOHC (Dual Overhead Camshaft), 4 valves per cylinder
Emission Standard: Typically Euro V

Applications: Primarily used in compact cars and sedans from the Volkswagen Group, such as the Golf Mk6, Jetta V, and Skoda Octavia Mk2.
