All-new 1.6L long-block engine for Chery SQR480ED
The Chery SQR480ED is a 1.6-liter naturally aspirated inline-four gasoline engine, primarily used in early Chery models such as the Chery Cowin and Chery Karry. It is part of the Chery ACTECO engine family.
Description
Key Specifications
Engine Type: Inline-4 gasoline engine
Displacement: 1,596 cc (1.6L)
Valvetrain: DOHC (Double Overhead Camshaft), 4 valves per cylinder
Maximum Power: 65 kW (87 hp) 5,500 rpm
Maximum Torque: 132 N·m 3,000–3,500 rpm
Engine Specifications
Cylinder bore: 79.96 mm
Piston stroke: 79.52 mm
Compression ratio: 9.75:1
Dry weight: Approx. 96 kg (long block)
Primary Vehicle Applications
Chery Cowin: 1.6L version
Chery Karry: 1.6L version
Chery Fulwin: 1.6L version
