2005–2015 Toyota Tacoma 4.0L 1GR-FE Engine (1st Generation V6 1GR Motor) — Applicable Models: Toyota 4.0L Series
The Toyota 1GR-FE is a 4.0-liter (3,956 cc) V6 gasoline engine that has been renowned for its exceptional reliability in pickup trucks and SUVs—such as the Tacoma, 4Runner, and FJ Cruiser—since entering production in 2002. This engine features a DOHC (Dual Overhead Camshaft) 24-valve design with a bore and stroke of 94 mm x 95 mm and a compression ratio of 10.0:1; its power output ranges from 236 to 285 horsepower, with peak torque falling between 266 and 278 lb-ft.
Description
Engine Specifications
Engine Type: 60-degree V6, 4-stroke gasoline engine
Displacement: 4.0L (3,956 cc)
Bore × Stroke: 95 mm × 95 mm (3.70 in × 3.74 in)
Valve Mechanism: DOHC (Dual Overhead Camshafts), 4 valves per cylinder, equipped with VVT-i (Intake Camshaft) or Dual VVT-i system
Compression Ratio: 10.0:1
Weight: 166 kg (366 lb)
Applicable Models: Toyota 4Runner, Tacoma, FJ Cruiser, Tundra, Land Cruiser, and Lexus GX 400
