1HZ crankshaft for Toyota Engine 13411-17012

Description

The key technical specifications for the Toyota 1HZ crankshaft are as follows:
Main journal diameter (standard value): 66.994 – 67.004 mm;
Connecting rod journal diameter (standard value): 58.994 – 59.004 mm;
Crankshaft end play: 0.040 – 0.240 mm (limit: 0.30 mm);
Main bearing clearance: 0.036 – 0.054 mm (limit: 0.10 mm);
Connecting rod bearing clearance: 0.036 – 0.054 mm (limit: 0.10 mm).

Dimensions and Material
Total length: Approx. 788 mm
Material: Cast iron
OE part number: Typically corresponds to 13411-17012 or 13411-17010
